Reinforced Concrete Detailing SOFTWARE
Professional Concrete Detailing Software for Generating Structural DrawingsGenerate, review, check and edit reinforcement details, structural drawings and rebar schedules directly from ETABS analysis and design results. ETABS MATE® is professional concrete detailing software for reinforced concrete structures. It transforms ETABS analysis and design results into detailed reinforcement information, structural drawings, reinforcement schedules and engineering reports, while giving engineers full control to review and edit the generated details. Key AdvantagesA practical detailing workflow combining speed, accuracy, engineering review and drawing production. Very High SpeedProcess structural and reinforcement information rapidly, even for large projects. High AccuracyGenerate consistent reinforcement details from structural analysis and design results. Structural ChecksReview important engineering conditions and reinforcement requirements during detailing. Full Editing ControlReview and modify reinforcement details before generating final structural drawings. High-Quality Structural DrawingsProduce clear, detailed and editable structural drawings for reinforced concrete structures. ETABS MATE Workflow
ETABS MATE bridges the gap between structural analysis and final
structural drawing production in just a few seconds.
From ETABS Results to Structural Drawings with ETABS MATE in Just a Few Clicks1
ETABS Analysis & DesignImport structural analysis and design results from ETABS quickly and easily.
→
2
Automatic DetailingTransform ETABS results into reinforcement details, rebar schedules and structural drawings. Review engineering conditions and edit reinforcement details as required before final drawing production.
→
3
Structural DrawingsProduce highly standardized, detailed and editable structural drawings with complete layer organization, together with rebar schedules. ETABS Compatibility: ETABS MATE is designed to work with all versions of ETABS and supports ETABS analysis and design results from all ETABS versions. See the ETABS MATE product page for more information. Reinforced Concrete DetailingDetailed reinforcement and drawing production for the principal reinforced concrete structural elements. Beam Detailing
Column Detailing
Shear Wall Detailing
Rebar Schedules
Engineering Checks & Detailing ControlsSelected engineering and detailing controls for reviewing important structural and reinforcement conditions. Joint Shear RatioCheck important shear conditions at beam-column joint panels. High-Shear BeamsIdentify beam conditions requiring attention to shear reinforcement and detailing. High-Compression ColumnsIdentify columns requiring special attention to transverse reinforcement and detailing under high axial compression forces. Hooked-Bar Development Length (Ldh)Control and review hooked-bar development length details. Reinforcement RequirementsReview reinforcement requirements and important detailing conditions. Reinforcement Arrangement & DetailingReview reinforcement arrangement and detailing controls before drawing production. Calculation Check ReportsGenerate reports to support engineering review and detailing verification. Detailing VerificationReview important detailing conditions before final structural drawing production. Full Editing ControlETABS MATE® gives engineers direct control over the generated reinforcement details and structural drawing output.
Designed for Any Scale ProjectsETABS MATE® is designed to handle both small and large reinforced concrete projects, with no limits on the number of stories or structural elements.
With about 15 years of development and extensive use by structural engineers, ETABS MATE® has been applied to a wide range of concrete projects in numerous countries and diverse project environments. Its combination of speed, automation, and detailed control makes it suitable for both
standard projects and large-scale and complex concrete structures.
Structural Drawing ExamplesExamples of structural drawings and reinforcement information generated by ETABS MATE®. Download the complete structural drawing sample in AutoCAD DWG format. The file contains the full drawing set for detailed review and use in AutoCAD-compatible software.
Detailing OutputsStandardized Structural DrawingsHighly standardized and fully editable structural drawings and schedules, delivered with complete layer organization for professional drawing production. Detailed Rebar Schedules
Organized reinforcement schedules for structural elements and
stories.
Material Lists
Organized material and reinforcement bar lists for project
review and planning.
Engineering Reports
Calculation check reports supporting engineering review and
detailing verification.
Explore ETABS MATE®Explore the ETABS MATE product page to see its concrete detailing workflow, structural drawings, reinforcement schedules, engineering reports, and editing capabilities, along with more features and detailed information about the software. Explore ETABS MATE®Frequently Asked QuestionsWhat is concrete detailing software?Concrete detailing software helps engineers transform structural analysis and design information into reinforcement details, structural drawings and reinforcement schedules for reinforced concrete structures. It supports the detailing process by organizing reinforcement information and helping engineers review the final structural output. Can ETABS MATE® generate structural drawings from ETABS results?Yes. ETABS MATE® uses ETABS analysis and design results to generate detailed reinforcement information, editable structural drawings, rebar schedules and engineering reports for reinforced concrete structures. What reinforced concrete elements can ETABS MATE® detail?ETABS MATE® provides detailing for major reinforced concrete structural elements, including beams, columns and shear walls. The software generates reinforcement details, structural drawings and organized reinforcement information for these elements. Can reinforcement details be reviewed and edited before final drawings?Yes. ETABS MATE® provides full editing control over generated reinforcement details. Engineers can review reinforcement arrangements, make required modifications, check detailing conditions and refine the drawings before final structural drawing production. Does ETABS MATE® generate rebar schedules?Yes. ETABS MATE® generates organized rebar schedules, including general and story-based reinforcement schedules as well as material and reinforcement bar lists. These outputs help organize reinforcement information for project review and planning. How can foundation and slab detailing be done?Foundation and concrete slab detailing can be performed using FOUNDA MATE ®, a companion software designed for foundation and slab detailing. FOUNDA MATE® helps engineers generate detailed reinforcement information and structural drawings for foundations and concrete slabs as part of the overall structural detailing workflow. What engineering checks are available during concrete detailing?ETABS MATE® provides selected engineering and detailing controls for reviewing conditions such as joint panel shear, high-shear beams, high-compression columns, hooked-bar development length, reinforcement requirements and other important detailing conditions. |
||||||
|
|
|||||
|
|
